12-1/4" x 3-1/2" Trailer Electric Brake , 0

√ Trailer Brakes √ 9,000 lb. – 12,000 lb. √ Electric Backing Plate √ Trailer Brake Assembly √ Self-Adjusting √ Electric Drum Brake The 12 1/4" x 3 1/2" electric brakes can fit AL-KO/Hays axles, but not for Dexter axles. Features l 12.25 x 3.5” Electric Brakes fit 5 mounting flange for 9k lb. to 12k lb. trailer axles. l Self-adjusting electric brake assembly keeps the brake adjusted automatically. l Fully assembled, compatible with most trailer axle manufacturers. l Fits 15" or larger wheels. Specifications Ø Dimension: 12.25 inch x 3.5 inch Ø Axle Capability: 9000 lbs to 12000 lbs Axle Ø Mounting Flange Bolt Pattern: 5 bolts (Mount plate has 6 holes, but normally only 5 are used) Ø Brake Fit: Left Hand / Driver Side / LH, Right Hand / Passenger Side / RH Product Composition ² 12 1/4” x 3 1/2" Electric Brake Shoe Set x 1 ² 5 Bolt Mounting Cast Backing Plate x 1 ² Magnet Lever x 1 ² Magnet x 1 ² Brake Adjuster x 1 ² Long Spring x 1 ² Short Spring x 2
