12-1/4" x 4" Trailer Electric Brake Asse, 0

√ Trailer Backing Plate √ 10,000 lb. √ Electric Brake Assembly √ Forward Self Adjusting (FSA) √ Trailer Drum Brakes √ Electric Drum Brakes √ 12 1/4” x 4” Drum √ Trailer Brakes 12-1/4" x 4" trailer electric brake assemblies are self-adjusting brakes, these 12.25 inch trailer brakes fit 10,000 lbs trailer axles. The mounting plate is 7 hole pattern. Features l 12.25” x 4” Trailer Drum Brakes fit 7 mounting flange for 10k lb. trailer axles. l Self-adjusting electric brake assembly don’t need for manual brake adjustments. l Completely assembled and easily installation, can exchange with most trailer brake manufacturers. l The brake linings are high quality non-asbestos, semi-metal friction material. l Fits 16" or larger wheels. Specifications Ø Dimension: 12.25 inch x 4 inch Ø Axle Capability: 10000 lbs Heavy Duty Axle Ø Mounting Flange Bolt Pattern: 7 bolts Ø Brake Fit: Left Hand / Driver Side / LH, Right Hand / Passenger Side / RH Product Composition ² 12 1/4” x 4" Electric Brake Shoe Set x 1 ² 7 Bolt Mounting Cast Backing Plate x 1 ² Magnet Lever x 1 ² Yellow Wire Magnet x 1 ² Brake Adjuster x 1 ² Long Spring x 1 ² Short Spring x 2
