12" x 2" Trailer Hydraulic Uni-Servo Bra, 1

√ Hydraulic Brake Assembly √ 12 x 2 inch Drum √ Trailer Brake Kits √ 5200 lbs, 6000 lbs, 7000 lbs √ 12” Hydraulic Brake √ Uni-Servo √ Trailer Axle Brakes √ Trailer Surge Brakes 12” x 2” hydraulic uni-servo brakes are replacement for one 5.2k – 7k lbs axle with 5 bolt pattern. The brakes are heavy duty application for 7000 lbs trailer axles. Every 12 inch hydraulic trailer brake assemblies have two pieces of non- asbestos semi metal brake shoes, bonded and riveted are available. The matched drums are 6 bolt or 8 bolt 12” brake drums. Technicians always recommend the customers to use hydraulic brake kit for tandem axles & torsion axles of boat trailers. Features l 12" hydraulic uni-servo brakes use with a surge-type trailer brake actuator (sold separately). l Manual adjustment – using fine tooth brake adjustment. l E-coated backing plates provide corrosion protection. l Pre-assembled and easy installation. l This trailer backing plate exchange with most standard hydraulic brakes, such as Dexter, Titan, Demco, Axletek, etc. Specifications Ø Dimension: 12 inch x 2 inch Ø Axle Capability: 5200 lbs Axle / 6000 lbs Axle/ 7000 lbs Axle (14.5”, 15", 16”, 16.5” Wheel) Ø Mounting Flange Bolt Pattern: 5 bolt Ø Brake Fit: Left Hand / Driver Side / LH, Right Hand / Passenger Side / RH Product Composition ² 12” x 2" Bonded Uni-Servo Brake Shoe Kit x 1 ² E-Coated Back Plate x 1 ² Single-Servo Wheel Cylinder x 1 ² Springs x 2
