Stainless Steel Trailer Hydraulic Disc Brake Calip, 0

√ Boat Trailer Hydraulic Disc Brake √ Hydraulic Disc Brake Caliper √ Hydraulic Disc Brakes √ 1400 KG (15”/16” WHEEL) √ Trailer Calipers √ 1600 KG (13”/14” WHEEL) √ Hydraulic Brake Caliper √ Stainless Steel Brake Caliper √ Trailer Brakes Caliper √ Ceramic Brake Pads The trailer brake caliper is stainless steel material, it has a phenolic piston and two pieces of ceramic brake pads. Upgraded trailer calipers have high rust-protection, high corrosion resistance and excellent anti-wear performance. The hydraulic trailer brake calipers suitable for boat trailers, box trailers and car trailers. This caliper will fit AL-KO trailer hydraulic disc brakes that use a 5 or 6 lug trailer disc rotor. Other specifications are same as the cast iron trailer hydraulic disc brake type. Features l Used with IQ7 or hydraulic over ride couplings (the load weights exceeding 2000 kg). l Requirement of disc hubs and rotors: Thicknesses from 12 mm to 15 mm. l Stainless steel caliper body and pads backing plate can prevent the corrosion of seawater. l Mounting bolts, spring washers and pads are included. Quick and easy installation. l This hydraulic disc brake calipers exchange with AL-KO and Trojan calipers, but have different appearance. Specifications Ø Axle Capability: 1400 kg (15”/16” wheel), 1600 kg (13”/14” wheel) Ø Mounting Bolts: 12mm H.T. x 45mm Ø Bolt Spacings: 88.9mm (3.5”) Ø Recommended operating pressure: 6.9 mpa (1000psi) Product Composition ² Non-asbestos semi-metal brake pads x 2 ² Galvanized Cast Iron Brake Caliper Body x 1 ² Bleed Screw x 1 ² Phenolic Resin Piston x 1 ² Piston Seal x 1 ² Piston Dust Boot x 1 ² Slide Pin Kit x 1 ² Slide Dust Boot x 2
